Name: ゴム製の鋼管
Uploaded: 2025-09-22T06:00:51+08:00
Description: ゴム製の鋼管

高性能の耐摩耗性ゴム製のスチールパイプ

最小注文数:1

梱包と配送



ゴム製の鋼管



製品について

耐摩耗性のゴム製のスチールパイプは、長寿命と低コストを提供します

（China Flange National Standard: GB/T 9119-2010）
No.	Specifications	Material No.	O.D. ΦD1	I.D. ΦD2	Wall Thickness t1	Liner Thickness t2	Length
No.	Specifications	PN10	O.D. ΦD1	I.D. ΦD2	Wall Thickness t1	Liner Thickness t2	Length
1	DN100PN10L	R-GZ-G-1001	108	80	4	10	2000
2	DN125PN10L	R-GZ-G-1001	133	105	4	10	3000
3	DN150PN10L	R-GZ-G-1001	159	130	4.5	10	3000
4	DN200PN10L	R-GZ-G-1001	219	189	5	10	3000
5	DN250PN10L	R-GZ-G-1001	273	243	5	10	3000
6	DN300PN10L	R-GZ-G-1001	325	283	6	15	3000
7	DN350PN10L	R-GZ-G-1001	377	335	6	15	3000
8	DN400PN10L	R-GZ-G-1001	425	373	6	20	6000
9	DN450PN10L	R-GZ-G-1001	480	426	7	20	6000
10	DN500PN10L	R-GZ-G-1001	530	466	7	25	6000
11	DN600PN10L	R-GZ-G-1001	630	564	8	25	6000
12	DN700PN10L	R-GZ-G-1001	720	654	8	25	6000
13	DN800PN10L	R-GZ-G-1001	820	752	9	25	6000

No.	Specifications	Material No.	O.D. ΦD1	I.D. ΦD2	Wall Thickness t1	Liner Thickness t2	L
No.	Specifications	PN16	O.D. ΦD1	I.D. ΦD2	Wall Thickness t1	Liner Thickness t2	L
1	DN100PN16L	R-GZ-G-2001	108	80	4	10	2000
2	DN125PN16L	R-GZ-G-2001	133	105	4	10	3000
3	DN150PN16L	R-GZ-G-2001	159	129	5	10	3000
4	DN200PN16L	R-GZ-G-2001	219	187	6	10	3000
5	DN250PN16L	R-GZ-G-2001	273	241	6	10	3000
6	DN300PN16L	R-GZ-G-2001	325	281	7	15	3000
7	DN350PN16L	R-GZ-G-2001	377	333	7	15	3000
8	DN400PN16L	R-GZ-G-2001	425	369	8	20	6000
9	DN450PN16L	R-GZ-G-2001	480	424	8	20	6000
10	DN500PN16L	R-GZ-G-2001	530	462	9	25	6000
11	DN600PN16L	R-GZ-G-2001	630	560	10	25	6000
12	DN700PN16L	R-GZ-G-2001	720	648	11	25	6000
13	DN800PN16L	R-GZ-G-2001	820	746	12	25	6000

No.	Specifications	Material No.	O.D. ΦD1	I.D. ΦD2	Wall Thickness t1	Liner Thickness t2	L
No.	Specifications	PN25	O.D. ΦD1	I.D. ΦD2	Wall Thickness t1	Liner Thickness t2	L
1	DN100PN25L	R-GZ-G-3001	108	78	5	10	2000
2	DN125PN25L	R-GZ-G-3001	133	103	5	10	3000
3	DN150PN25L	R-GZ-G-3001	159	127	6	10	3000
4	DN200PN25L	R-GZ-G-3001	219	185	7	10	3000
5	DN250PN25L	R-GZ-G-3001	273	237	8	10	3000
6	DN300PN25L	R-GZ-G-3001	325	277	9	15	3000
7	DN350PN25L	R-GZ-G-3001	377	329	9	15	3000
8	DN400PN25L	R-GZ-G-3001	425	365	10	20	6000
9	DN450PN25L	R-GZ-G-3001	480	418	11	20	6000
10	DN500PN25L	R-GZ-G-3001	530	456	12	25	6000
11	DN600PN25L	R-GZ-G-3001	630	554	13	25	6000
12	DN700PN25L	R-GZ-G-3001	720	640	15	25	6000
13	DN800PN25L	R-GZ-G-3001	820	738	16	25	6000
